HPV-8, 12, 16, 20, 23 Variable Pump
Pump Capacity: 8~23 cm³/rev
Operating Pressure:1.5~25 Mpa
Max. Pressure: 25 Mpa
High-pressure variable pump designed specifically for deep-hole drilling. Made with wear-resistant materials to significantly enhance wear resistance and high anti-fouling performance.
Features low pulsation impact, high stability, and long service life. Capable of automatically adjusting flow and pressure, making it highly convenient for machining workpieces with different bore diameters.Very good response and recovery times. Conforms to the latest SAE and ISO standard.
Specifications:
| Model | Pump capacity (cm³/rev) | Operating Pressure Mpa(Kgf/cm²) | Max. Pressure Mpa(Kgf/cm²) | No-load discharge Rate(L/min) | Weight (kg) | |
| 50HZ | 60HZ | |||||
| HPV-R8H | 8 | 1.5~25 (15.3~255) | 25 (255) | 12 | 14.4 | 16 |
| HPV-R12H | 12 | 18 | 21.6 | |||
| HPV-R16H | 16 | 24 | 28.8 | |||
| HPV-R20H | 20 | 30 | 36 | |||
| HPV-R23H | 23 | 34.5 | 41.4 | |||
